Laser Cleaning Head
JST25A
JST25A is developed on the basis of SUP23S handheld laser cleaning head. Compared with the previous SUP23S, it is further improved in insulation, stability, maintenance and other aspects, and has more compact, lighterand more reliable characteristics.
1. Self-developed control system, multiple safety alarms, active safety power-off, and laser-off settings;
2. Smaller size, flexible operation,and easy to use;
3. Compatible with various types of fiber lasers;
4. Optimized optics and water cooling design.
|
Supply Voltage(v) |
220±10%V AC 50 / 60Hz |
|
Placement Environment |
Flat, No Vibration and Impact |
|
Working Temperature Environment(℃) |
10-40 |
|
Working Environment Humidity (%) |
<70 |
|
Cooling Method |
Hydrocooling |
|
Applicable Wavelength |
1064nm(±10nm) |
|
Applicable Power |
≤3000W |
|
Collimating Lens |
D16*5 / F60 |
|
Focusing Lens |
D20*3.5 (F400 / F600 / F800) Choose One Focal Length You Want |
|
Reflective Mirrors |
20*15.2*T1.6 |
|
Protective Windows Specifications |
D30*T5 |
|
Maximum of Support Pressure |
15Bar |
|
Adjustment Range of Spot |
±10mm |
|
Scan Width-Wash |
F400-0~150mm |
|
F600-0~225mm |
|
|
F800-0~300mm |
|
|
Weight |
0.7KG |
