Solve Your Cutting Problems at the Root
If you are facing:
- Dross on stainless steel
- Burrs on aluminum
- Unstable cutting quality
- Frequent nozzle replacement
In most cases, the real issue is nozzle misalignment, not parameters.
The BOCHU nozzle visual alignment tool helps you quickly and accurately center the laser beam, ensuring stable gas flow and consistent cutting performance.
| Name | Model | Welding Head Model |
| Plaser nozzle visual aligner | BOCHU MCD100 | For BOCHU-BOCI/ Raytools/ Bodor/ WSX/ OSPRI |
Why Nozzle Alignment Matters
Even a small deviation:
- 0.05–0.1 mm offset
→ causes uneven assist gas flow
→ results in dross, slag, rough edges
👉 Many operators adjust parameters repeatedly
but ignore the real issue: beam is not centered
Precision
High precision alignment (≤0.01 mm)
Durable
Real-time visual positioning system
Fast setup
Fast setup, no trial-and-error
Versatile
Suitable for various laser cutting heads
🔹 Traditional Method vs Visual Alignment
❌ Traditional Tape Shot Method
- Requires laser firing
- Risky for operator
- Depends on experience
- Time-consuming (5–10 minutes)
- Results not repeatable
✅ BOCHU Visual Alignment Tool
- No laser firing required
- Real-time camera display
- Clear beam position visualization
- Alignment completed in 1–2 minutes
- Consistent and repeatable
👉 Even new operators can achieve perfect alignment
🔹 How It Works (3 Simple Steps)
- Place the alignment tool under the nozzle
- Camera displays nozzle center and beam position
- Adjust screws until beam is perfectly centered
👉 Done in minutes — no repeated testing needed
🔹 Real Benefits for Your Production
- ✔ Reduce dross and burrs significantly
- ✔ Improve cutting edge quality
- ✔ Stabilize cutting performance
- ✔ Reduce nozzle wear and damage
- ✔ Save setup and troubleshooting time
- ✔ Lower scrap rate
👉 This is not just a tool
👉 It is a cutting quality improvement solution
FAQ
Q: Do I need to fire the laser during alignment?
No. Visual alignment works without laser emission.
Q: How accurate is this tool?
Up to 0.01 mm, much more reliable than manual methods.
Q: Is it only for BOCHU heads?
Mainly optimized for BOCHU BLT series, but compatible with Raytools, Bodor, WSX and OSPRI.
Q: Can beginners use it?
Yes. No experience required — visual guidance makes it easy.
🔹 Why Choose This Tool
Most factories try to fix cutting issues by:
- adjusting parameters
- changing gas pressure
- replacing consumables
👉 But the root cause is often ignored.
This tool helps you fix the problem at its source:
accurate beam-to-nozzle alignment
