20W Fiber Laser Marker
Brogo’s 20W fiber laser marking machine is your ultimate resource for engraving words, logos, pictures, barcodes, and more on metal and other materials with quick turnaround and perfect accuracy.
Independently Adjustable Pulse Frequency and Width
Cutting-Edge Laser Source
This fiber marking machine’s world-famous laser source offers stable and dependable operation, with a mean time to failure exceeding 100,000 hours.
Unparalleled accuracy achieved
Producing less than 1% distortion, it flawlessly executes intricate designs with unbelievable precision.
Field Lens
Our Field Lens creates vivid markings on flat surfaces by maintaining a consistent, focused laser spot size across its 4.3″×4.3″ (110×110 mm) working area.
10,000 mm/s Max. Marking Speed
Our fiber laser engraver effortlessly achieves speeds of up to 10,000 mm/s to improve your work efficiency.
Let Your Imagination Run Wild
Break free from material constraints and experience unparalleled versatility in your laser engraving projects.
Find Your Perfect Match: Power-Scalable Solutions for Every Budget
From small workshops to heavy-duty industrial sites – we’ve got you covered.
Parameter | 100W | 200W | 300W |
Maximum average power (W) | 100 | 200 | 300 |
Power range (%) | 10-100 | ||
Output central wavelength (nm) | 1064 | ||
Bandwidth (nm) | 5 | ||
Maximum pulse energy (mJ) | 2 | 2 | 2 |
Pulse repetition rate (kHz) | 100-120 | 100-120 | 100-120 |
Pulse width (ns) | 180±10@65kHz | 220±10@130kHz | 220±10@130kHz |
Beam quality (M²) | 1.6 | ||
Fiber length (m) | 1.5 | ||
Minimum bending radius (mm) | 150 | ||
System power requirements (V) | 220 | ||
Power consumption (W) | 500 | 800 | 900 |
Operating temperature (℃) | 10-40 | ||
Storage temperature (℃) | -10-60 | ||
Relative humidity (%) | <80 | ||
System dimensions (mm) | 345*192*469 | 345*192*469 | 345*192*469 |
Total weight (kg) | 7.8 | 10.5 | 15.5 |
Laser head weight (kg) | <0.75 | ||
Laser head type | 2D scanning | ||
Scanning range (mm) | 130×130 | ||
Focal length (mm) | 230 | ||
Operating mode | Manual/Auto | ||
Safety class | Class 4 | ||
Frequently Asked Questions!
Brogo’s machine can engrave various materials including metals, hard plastic, stone, leather and more.
Yes, it is fully compatible with LightBurn software, offering customizable features and user-friendly controls.
It comes bundled with EZCad software and is compatible with LightBurn software (not included).
Yes, it features a rotary axis connection port for engraving rings, bracelets, and other curved surfaces.
With its plug-and-play design and user-friendly controls, operation is seamless and straightforward.
The laser source lasts for over 100,000 hours, ensuring long-lasting performance.
The Dual Red Dot Locators are a key feature of our fiber laser marking machine, designed to significantly enhance its precision and user-friendliness.
These locators work by projecting two red dots onto the material you’re working with, providing a visual guide that helps you quickly and accurately align and focus the laser before marking begins.
This technology not only simplifies the setup process but also ensures that each mark is exactly where it needs to be, leading to consistent, high-quality results.
Whether you’re working on intricate designs or precise industrial markings, the dual red dot locators make achieving professional-grade accuracy faster and more efficient.
The machine provides a spacious 4.3×4.3 inch (110×110 mm) field for handling projects of various sizes.
It operates at a speed of 10,000 mm/s for quick scanning, engraving, and turnaround.
